Doosan VC430 Dual Pallet Machine VERTICAL MACHINING CENTERS. VMC's

Price on Request

Make:: Doosan

Model:: VC430 Dual Pallet Machine

Year:: 2011

Ref #:: 178249

Or call us for a quote at (973) 497-7500 or send us an email at cncmachines@machineryvalues.com

DOOSAN TWIN TABLE VERTICAL MACHINING CENTER
MODEL: VC 430, NEW: 2011

SPECIFICATIONS:
X-AXIS TRAVEL ......................... 22"
Y-AXIS TRAVEL ......................... 16.9"
Z-AXIS TRAVEL ......................... 22.4"
MAXIMUM SPINDLE SPEED ................. 10,000 RPM
SPINDLE TAPER ......................... CAT 40
SPINDLE MOTOR ......................... 25 HP
AUTOMATIC TOOL CHANGER ................ 30 TOOLS
PALLET SIZE ........................... 28" X 19.3"
NUMBER OF PALLETS ..................... 2
PALLET CHANGE TIME .................... 5 SECONDS
PALLET LOADING CAPACITY ............... 661 LBS/EACH
SPINDLE TO PALLET SURFACE ............. 5.928
DIMENSIONS .................... 87" L  X 114" W X 108" H
(PLUS 37" FOR CHIP CONV) (122.4" HEIGHT MAX)
APPROXIMATE WEIGHT .................... 17,200 LBS

EQUIPPED WITH:
FANUC I CNC CONTROL
(2) PALLETS
SIDE MOUNTED 30 POSITION AUTOMATIC TOOL CHANGER
CHIP CONVEYOR
COOLANT THROUGH THE SPINDLE
NEW SPINDLE DONE APPROXIMATELY ONE YEAR AGO

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
