Edge Tech PATRIOT 551 BAR FEEDS

$7,950

Make:: Edge Tech

Model:: PATRIOT 551

Year:: 2011

Ref #:: 177961

Or call us for a quote at (973) 497-7500 or send us an email at automatics@machineryvalues.com

EDGE TECHNOLOGIES PATRIOT 551 AUTOMATIC BAR LOADER
FULL 6' BAR CAP, NEW 2011
CAN LOAD UP TO 8'BARS, 42mm CHANNEL INSTALLED

Equipped with:
Configured with a 42mm Channel Set
(additional channel sets can be purchased. Price on request)

New Replacement $38,000

Originally on an Okuma Genos L400, should configure to almost all CNC Turning Centers

Specifications:
Capacity . . . . . . . . . . . . . . . 2"
Bar Length . . . . . . . . . . . . . . 8"
Length of Spindle Type . . . . . . . . No
Synch for Sliding Headstock . . . . . .No
Axial Shift . . . . . . . . . . . . . .No
Dimensions . . . . . . . . . . . . . . 128" x 28" x 49"
Weight . . . . . . . . . . . . . . . . 2,200 lbs.

To the best of our knowledge all details listed below are deemed correct.
It is the buyer's responsibility to confirmed prior to purchase.

General Specifications per Manufacturer

Bar Capacity:
   No Prep:                         5mm to 44.5mm (.196" to 1.75")
   With Prep:                       5mm to 51 mm (.196" to 2.000")
Maximum Bar Length:                 8'
Minimum Bar Length:                 39.4"
Maximum Remnant Length:             16"
Magazine Rack Capacity:             12"
Bar Loading Cycle:                  30 seconds for 12' bar
Material Straightness Specifications:.007"TIR/ft of material
                                     (V Blocks, 3 points equidistant)
Feed Force (pusher torque):          max 450N, adjustable
Foward Feed Rate:                    750 inches/min max, adjustable
Return Feed Rate:                    1000 inches/min max, adjustable
Power Consumption:                   1.5kW
Operating Voltage:                   230V/60 Hz - 3 phase
Control Voltage:                     24V DC
Oil Capacity:                        57 liters (15 gallons)
Oil Viscosity:                       ISO 150cST
Compressed Air Supply:               6 bar (90 psi)
Compressed Air Consumption:          approx. 8 liters/loading cycle

Barfeed: 133" x 28" x 49" 2,100 lbs

To the best of our knowledge all details listed below are deemed correct. It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.
