Fadal VMC-3016FXMP-HT VERTICAL MACHINING CENTERS. VMC's

$26,500

Make:
Fadal
Model:
VMC-3016FXMP-HT
Year:
2008
Ref #:
159477

Or call us for a quote at (973) 497-7500 or send us an email at cncmachines@machineryvalues.com


FADAL VERTICAL MACHINING CENTER
MODEL: VMC-3016FXMP HT, NEW: 2008

SPECIFICATIONS:
X-AXIS TRAVEL.......................... 30"
Y-AXIS TRAVEL.......................... 16"
Z-AXIS TRAVEL.......................... 20"
TABLE SIZE............................. 39" X 16"
MAXIMUM WEIGHT ON TABLE................ 2,736 LBS
SPINDLE NOSE TO TABLE.................. 4" TO 24"
SPINDLE CENTER TO COLUMN WAYS.......... 16"
SPINDLE SPEEDS......................... 10 TO 10,000 RPM
SPINDLE MOTOR (OPTIONAL HIGH TORQUE)... 22.5 HP
SPINDLE TAPER.......................... CAT 40
ATC, NUMBER OF TOOLS................... 21
NO. OF GROUND BOXWAYS PER AXIS (X/Y/Z). 2
MACHINE SIZE: 98" WX 77" D X 103" H
MACHINE WEIGHT: 8.550 LBS
POWER REQUIRED: 51 AMP, 240/3/60

EQUIPPED WITH:
- FADAL MP CNC CONTROL
- RIGID TAPPING
- HIGH TORQUE
- BOX WAYS
- COOLANT SYSTEM
- 15 HORSE POWER SPINDLE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
