Giddings & Lewis 42" VERTICAL BORING MILLS & VERTICAL TURRET LATHES

Price on Request

Make:
Giddings & Lewis
Model:
42"
Year:
1999
Ref #:
159198

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


42" GIDDINGS & LEWIS VERTICAL BORING MILL
S/N: 42R-1050 - BUILT 1958, REBUILT 1999 -

SPECIFICATIONS:
DIA OF 4-JAW COMBINATION CHUCK ...... 42"
MAX SWING WITH SIDE HEAD DOWN ....... 52"
MAX SWING WITH SIDE
-HEAD IN WORKING POSITION ........... 46"
MAX DISTANCE UNDER CROSS RAIL ....... 37"
MAX DISTANCE UNDER TURRET FACE ...... 49"
TURRET TRAVEL ....................... 33"
RAM AND TURRET HEAD SWIVELS ......... 60 DEGREES TOTAL
MAX DISTNCE UNDER RAM FACE .......... 42"
RAM HEAD TRAVEL ..................... 33"
SIDE HEAD TRAVEL .................... 21"
SIDE HEAD VERTICAL TRAVEL ........... 37"
24 TABLE SPEEDS ..................... 6 TO 320 RPM
20 FEED RANGES ...................... .0007 TO .576 IPR
FLOOR SPACE ......................... 9'X 10' X 10'
MACHINE WEIGHT ...................... 33,500 LBS

EQUIPMENT:
5 POSITION MANUAL INDEXING TURRET HEAD,
HEAVY DUTY SWIVELING RAM HEAD,
4 POSITION POWER SIDE HEAD,
HEIDEHEIM DIGITAL READ OUTS,
PENDANT CONTROLS,
(3) TOOLHODERS AND GUARDS
