Giddings & Lewis RT1250 CNC TABLE TYPE HORIZONTAL BORING MILLS

Price on Request

Make:: Giddings & Lewis

Model:: RT1250

Year:: 2008

Ref #:: 175660

Or call us for a quote at (973) 497-7500 or send us an email at boringmills@machineryvalues.com


5.1" GIDDINGS & LEWIS
CNC TABLE TYPE HORIZONTAL BORING MILL
MODEL: RT1250,  NEW: 2008

SPECIFICATIONS:
SPINDLE DIAMETER ..................... 5.1" (130 mm)
SPINDLE TAPER ........................ #50 ANSI
SPINDLE TRAVEL ....................... 31.5" (800 mm)
TABLE CROSS TRAVEL (X AXIS) .......... 98.4" (2500 mm)
HEADSTOCK TRAVEL ABOVE TABLE ......... 82.7" (2100 mm)
VERTICAL HEAD TRAVEL, ABOVE TABLE .... 78.7" (2000 mm)
SADDLE TRAVEL (W AXIS) ............... 59.05" (1500 mm)
TABLE SIZE (BUILT IN ROTARY) ......... 49.2" X 63" (1250 mm x 1600 mm)
TABLE LOAD CAPACITY .................. 33,100 LBS.
TABLE INDEXABLE ...................... 0.001
ROTARY B-AXIS FEED ................... 0 - 6 RPM
SPINDLE SPEEDS VARIABLE TWO RANGES:
   LOW RANGE ......................... 10 - 1000 RPM
   HIGH RANGE ........................ 1000 - 4000 RPM
RAPID TRAVERSE, X,Y,Z & W ............ 985 IPM
APPROXIMATE WEIGHT ................... 70,000 LBS

EQUIPPED WITH:
FANUC 310I CONTROL W/15" LCD MONITIOR
SOFTWARE FOR CH FACING HEADS & PROGRAMMABLE BORING BARS
TWO CHIP CONVEYORS, ONE ON EACH SIDE OF THE BED
RENISHAW PART PROBE
COOLANT THROUGH THE SPINDLE 8 BAR (116 PSI)
FULL COOLANT & CHIP ENCLOSURE
60 POSITION TOOL CHANGER
BUILT IN CONTOURING ROTARY TABLE W/ PROGRAMMABLE
   MECHANICAL CLAMP

INSPECT UNDER POWER IN A US PLANT
