Studer S33CNC UNIVERSAL CYLINDRICAL GRINDERS

Price on Request

Make:
Studer
Model:
S33CNC
Year:
2009
Ref #:
174560

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com


  13.8" x 25.6" Studer S33 CNC
  Universal Cylindrical Grinder

** Made in Switzerland **

New 2009

SPECIFICATIONS:
– Distance CC ………… 25.6″
– Height………… …………  6.9″
– Workpiece weight – maximum ……… 176 Lbs.

Cross slide – X-axis:
– Travel – maximum ………… 11.2″
– Infeed speed – programmable ………… 0.000,04 – 197 IPM

Longitudinal slide – Z-axis:
– Travel – maximum…………31.5″
– Infeed speed – programmable…………0.000,04 – 193 IPM
- table swivel range ………… +8.5 Degs.

- Measuring system resolution (X&Z)
  – rotary absolute…………0.000,004″

Wheelhead:
– Stops – positive…………0 Deg./30 Deg.
                     with Air Cushion Lift
– Drive power…………1 0 HP

Wheel peripheral speeds:
– 20″ Wheel…………8,661 SFPM
– 16″ Wheel…………6,890 SFPM
– 12″ Wheel…………5,118 SFPM

Universal Workhead:
– Speed range…………1 – 1,500 RPM
– Inching speed…………1 – 50 RPM
– Taper………..Morse 5

Tailstock:
– Taper…………Morse 4
– Stroke…………2.36″
– Barrel…………1.97″ Diameter
– Fine adjustment for
   taper corrections…………+/- 0.0016″
EQUIPPED WITH:
Fanuc 21i-TB control w/pendant
 and RS232 Interface (Studer operating system)
In-Process Locator/Probe
Table swivel fine adjustment
Manual swivel wheelhead w/air cushion lift-off
Air cooled spindle drive motor
Workhead pneumatic lift
Regular C-Axis for cylindrical grinding
Double foot pedal for clamping devices
Manual tailstock w/fine adjustment,
Hydraulic controlled barrel retraction
Granitan base and vibration reducing mounting pads
Full enclosure
Coolant filtration system
 w/interface for coolant distribution
