Turnmaster 1340G ENGINE LATHES

$4,950

Make:
Turnmaster
Model:
1340G
Year:
2002
Ref #:
159829

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


13"/20" x 40" AMERICAN-TURNMASTER GAP BED ENGINE LATHE
MODEL: 1340G,  S/N: 13402111526,  NEW: 2002

SPECIFICATIONS:
SWING OVER BED ....................... 13.4"
SWING OVER CROSS SLIDE ............... 8.3"
SWING IN REMOVEABLE GAP .............. 20"
DISTANCE BETWEEN CENTERS ............. 40"
WIDTH OF BED ......................... 9.1"
HOLE THRU SPINDLE .................... 1.6"
SPINDLE NOSE, CAMLOCK SIZE ........... D1-4"
SPINDLE SPEEDS (16) .................. 50 - 2,570 RPM
TAILSTOCK SPINDLE TAPER .............. #3 MORSE
TAILSTOCK SPINDLE TRAVEL ............. 4.4"
TAILSTOCK SPINDLE DIAMETER ........... 2"
FEEDS:
    LONGITUDINAL ..................... .0015 - .067 IPR
    CROSS ............................ .001 - .034 IPR
THREADS:
    INCH (45) ........................ 2 - 72 TPI
    METRIC (39) ...................... .2 - 14 mm
DIMENSIONS ........................... 70" x 40" x 50"
APPROX WEIGHT ........................ 2,850 LBS

EQUIPPED WITH:
- QUICK CHANGE UNIV GEARBOX PROVIDES WIDE RANGE OF INCH/METRIC FEEDS & THREADS
- REMOVEABLE GAP BLOCK
- TRAK TWO AXIS DIGITAL READOUT
- 3-JAW CHUCK
- ALORIS MODEL: BXA QUICK CHANGE TOOLPOST & HOLDERS
- THREADING DIAL
- DRILL CHUCK FOR TAILSTOCK
- LIVE CENTER FOR TAILSTOCK
- SELF CONTAINED COOLANT SYSTEM
   w. FULL LENGTH REAR SPLASH GUARD
- INDUCTION HARDENED BEDWAYS
- 5 HORSE POWER SPINDLE DRIVE MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
