Victor 618EM PRECISION LATHES LIKE HARDINGE

$12,950

Make:
Victor
Model:
618EM
Year:
1990's
Ref #:
159577

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


VICTOR PRECISION TOOL ROOM LATHE
MODEL: 618EM, S/N: 8605185, NEW: 1990'S

SPECIFICATIONS:
CAPACITY
  W/ROUND TYPE 5C COLLETS ............. 1-1/16"
  W/STEP CHUCKS ....................... 1-1/16" TO 6"
  W/JAW CHUCKS ........................ 5"
  W/EXPANDING COLLETS ................. 3"
VARIABLE SPINDLE SPEEDS ............... 0 - 4,000 R.P.M.
HOLE THROUGH SPINDLE .................. 1-1/4"
SWING OVER BED ........................ 11"
SWING OVER CARRIAGE ................... 9"
SWING OVER CROSS SLIDE ................ 6"
DISTANCE BETWEEN CENTERS .............. 18"
COMPOUND SLIDE TRAVEL ................. 3"
CARRIAGE POWER FEED RANGE ............. 5/16 - 7 IPM
CROSS SLIDE POWER FEED RANGE .......... 3/16 - 4 IPM
TAILSTOCK SPINDLE DIAMETER ............ 1-3/8"
TAILSTOCK SPINDLE TAPER ............... #2 MT
INCH THREADING RANGE IN GEARBOX ....... (36) 11 - 108 T.P.I.
METRIC THREADING RANGE IN GEARBOX ..... (36) 0.275 - 2.7 MM
APPROXIMATE WEIGHT .................... 2,000 LBS.

EQUIPPED WITH:
- DUAL GEARBOX FOR PRECISION ENGLISH OR METRIC THREAD CUTTING
- DUAL READING INCH/METRIC DIAL FOR COMPOUND AND TAILSTOCK
- BALL BEARING QUICK ACTING 5C COLLET CLOSER
- ALORIS QUICK CHANGE TOOLPOST WITH HOLDERS
- HALOGEN WORK LIGHT
- SELF-CONTAINED COOLANT SYSTEM
- 1 HORSE POWER MAIN MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
