Acer AGS-1230AHD NEW SURFACE GRINDERS

Price on Request

Make:: Acer

Model:: AGS-1230AHD

Year:: NEW

Ref #:: 158860

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

"NEW" ACER HIGH PRECISION SURFACE GRINDER
MODEL: AGS-1230AHD - 3 Axis Automatic

FEATURES: (3-Axis Auto Movement)
Precison "Turcite-B" Ways
Hydraulic Table & Electronic Cross Feed
Auto Incremental Downfeed
Auto Lubrication
Rapid Elevation
Working Capacity: 12" x 30"

SPECIFICATIONS:
Longitudinal Travel: 33.1"
Cross Feed Travel: 13.1"
Spindle Cneter to Table: 23-1/2"
Table Size: 12" x 30"
Wheel Speed: 1,750 RPM
Spindle Motor: 5 HP
Auto. Increment Downfeed: Variable 10-step (0.0001"~0.001")
Table Speed: 16 ~ 80 ft/min
Wheel Size: 14"(OD) x 1-1/4"(W) x 5"(ID)
Vertical Graduation: 0.0005"
Vertical Revolution: 0.1"
T-Slot: 1" x 9/16"
Net Weight: 4,290 lbs.

STANDARD ACCESSORIES:
Coolant System with Paper Filter
Manual Overhead Parallel Dresser
12" x 28" Acer Electro-Magnetic Chuck
Variable Chuck Control Master

OPTIONAL ACCESSORIES:
Walker 12"x24" Electro Fine Pole Chuck with Control
Coolant System w/ Magnetic Separator & Paper Filter(1010+M2)
Extra Wheel Flange
Newall 2-Axis D.R.O. (16"x24" Travel, 0.0001" Resolution)
Magnescale 2-Axis D.R.O. (16"x24" Travel, 0.00002" Resolution)
