LeBlond-Makino 15" Regal Servo-Shift ENGINE LATHES

$14,500

Make:: LeBlond-Makino

Model:: 15" Regal Servo-Shift

Year:: 1994

Ref #:: 172450

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

15" x 54" LEBLOND-MAKINO SERVO SHIFT ENGINE LATHE
MODEL: 15" REGAL, S/N: 15C-1006, NEW: 1994

SPECIFICATIONS:
SWING OVER BED .................... 15-1/2"
SWING OVER CROSS SLIDE ............ 9-1/2"
DISTANCE BETWEEN CENTERS .......... 54"
SPINDLE NOSE THREAADED ............ L1
HOLE THRU SPINDLE ................. 2-17/64"
SPINDLE SPEED RANGE (12) .......... 30 - 1200 RPM
LONGITUDINAL FEED RANGE (48) ...... .0018" - .104" IPR
CROSS FEEDS HALF THE VALUES OF LONGITUDINAL
THREADING RANGE ENGLISH (48) ...... 2 - 112 TPI
THREADING RANGE METRIC (40) ....... 0.25 - 14 mm
TAILSTOCK SPINDLE TRAVEL .......... 5"
TAILSTOCK SPINDLE TAPER ........... #4 MT
APPROX WEIGHT ..................... 3,300 LBS
APPROX DIMENSIONS ................. 104"L x 40"W x 51"H

EQUIPPED WITH:
INCH & METRIC THREADING CAPABILITY
INCH/METRIC HANDWHEELS
10" 3-JAW BISON CHUCK
TAPER TURNING ATTACHMENT
ALORIS MODEL: CA QUICK CHANGE TOOLPOST
FOLLOW REST
DEAD CENTER FOR TAILSTOCK
THREAD DIAL INDICATOR
MICROMETER CARRIAGE STOP
COOLANT SYSTEM WITH REMOVABLE CHIP PAN
HARDENED & GROUND REPLACEABLE BEDWAYS
7.5 HORSE POWER MAIN MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE

CONDITION:    ****  EXCELLENT  ****
