Okamoto ACC-12-24 DXNCP CNC SURFACE GRINDERS

Price on Request

Make:
Okamoto
Model:
ACC-12-24 DXNCP
Year:
2007
Ref #:
153601

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com


  12" X 24" OKAMOTO "HIGH-PRECISION" CNC PROFILE SURFACE GRINDER
  WITH “FANUC 21i-MB” CNC CONTROL

** REPLACEMENT COST FOR THIS MACHINE IS OVER 170K
    AS EQUIPPED!  HOLY COW! **

 MODEL: ACC-12-24DXNC-P     S/N: 63534     NEW: 2007

TABLE CAPACITY:
NOMINAL GRINDING CAPACITY ....................... 12" x 24"
MAXIMUM HEIGHT UNDER 12" WHEEL ...................... 13.6"

LONGITUDINAL FEED (X AXIS):
TABLE SPEED, INFINITELY VARIABLE ........... 3' TO 82' FPM
MAX. LONGITUDINAL TABLE MOVEMENT, MANUAL ............ 26.0"
FEED PER HANDWHEEL REVOLUTION ....................... 1.85"

CROSSFEED (Z AXIS):
MAX. SADDLE TRAVEL ................................... 9.0"
INTERMITTENT TRAVERSE FEED  .......... 0.002" TO 0.40" IPM
GRINDING FEED .......................... 0.001" TO 40" IPM
RAPID FEED ....................................... 40" IPM
JOG FEED .................................... 0 TO 40" IPM
MANUAL PULSE GENERATOR ............ 0.00001", .0001", .001"

VERTICAL FEED (Y AXIS):
GRINDING FEED .......................... 0.001" TO 40" IPM
INTERMITTENT DOWN FEED  .. ............ 0.00001" TO 0.004"
RAPID FEED ....................................... 40" IPM
JOG FEED .................................... 0 TO 40" IPM
MANUAL PULSE GENERATOR ............ 0.00001", .0001", .001"

GRINDING WHEEL:
SPINDLE MOTOR ......................... 5.5 Kw - 7.375 H.P.
WHEEL SIZE ......................... 12"DIA. x 1.5"W x 5"B
SPEED ................................. 1,000 TO 3,600 RPM

APPROX. DIMS. FOR OPERATION ........... 135" x 77"D x 95"H
APPROX. MACHINE WEIGHT ........................ 6,000 LBS.

EQUIPPED WITH:
ASAHI RDU-WL DIAMOND ROTARY DRESSER
OIL TEMPERATURE REGULATOR UNIT
COOLANT SYSTEM WITH MAGNETIC SEPARATOR
MACHINE TOOL ENCLOSURE
MACHINE IS PRESENTLY WIRED FOR 3/60/230 VOLTS

 MACHINE FEATURES:
 CNC Unit (FANUC 21i-MB)
 Controlled Axis 2 Axis (2 SIM.)
 MIN. Increment Y - axis (Vertical) 0.00001”
  Z - axis (Saddle) 0.00001”
 MAX. Programmable Digits  ±8 digits
 Grind Feed Rate Override  0 - 150%
 Rapid Feed Rate Override  0, 25, 50, 100 %
 Manual Pulse Feed Increments 0.00001, 0.0001, 0.001”
 Preparatory Functions  M - Codes (2-digits)
 Automatic Acceleration/Deceleration
 Manual Continuous Feed
 Interpolation (Linear / Circular)
 Dwell Time
 Machine Lock
 Skip Function
 Stored Pitch Error Compensation
 Dry Run
 Single Block
 Self-Diagnosis Function
 Coordinate System Setting
 Pocket Calculator Type Decimal Point Programming
 Custom Macro B (Option)
 Inch / Metric Conversion
 Cutter Compensation C
 Input / Output Interface RS232C
 Part Program Storage Length (Total 262.5 FT)
 No. of Registered Programs: 63 Programs
 External Message

Machine Features
Built-In Okamoto Conversational Programming System .... developed by Okamoto and based
 on our long experience with many different types of grinding applications.  This software is based
 on the three basic types of grinding ... Form (Plunge), Surface, and Multiple-Step.
 The Conversational Programming promotes fast, easy set-up.  Saves time...boosts productivity.
 When you need more flexibility in grinding, an RS232 Port and PC Card slot
 is available for G & M code programming transfer.



“Teach” Input Programming System ... Operator simply moves the grinding wheel manually
 to the grinding start position and using an input key teaches that position to the machine,
 then he moves the wheel to the cross reversal position and using the input key, teaches that
 position to the machine, etc. He then inputs stock removal, air cut, dressing interval, etc.
 and the control automatically calculates total movement and all start and stop points.

“Drawing” Input Programming System ... Input the actual dimensions from the
  workpiece drawing and the control automatically calculates the cycle sequence.
Built-In Conversational Dress Programming ... is based on the three basic types
 of dressing menus -- “Side”, “R”, “V”, and “SLOT”. “FREE” style may also be used utilizing
 “G” and “M” Code programming. All of the three basic types of dressing menus have
 the capability to dress the following forms.


• Vertical & Cross Incremental Feed ... with Multipliers of 0.00001”/0.0001”/0.001”.

• Automatic Lubrication...All DXNCP Models utilize a proven Gravity Feed Automatic Lubrication System.
 Lubrication oil is pumped to an oil reservoir located at the top of the column and is gravity fed
 to all guideway surfaces and positioning screws.

• Extended Saddle and Table Ways ... Reduced overhand of the saddle and table at
 maximum limits provide long effective life of the machine tool and ensure its built-in accuracy.


• Double-Walled Column Construction ... H-Shaped guideways with 3 tapered gibs provide the strength


Double Vee Way Table & Saddle Construction ... providing true tracking, greater table load
 support, and longer life of the built-in accuracy.

** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
** EXCEPTIONAL CONDITION & APPEARANCE - ALL ORIGINAL - LOW HOURS ON MACHINE **
