Poreba TPL90 HOLLOW SPINDLE ENGINE LATHES

$79,500

Make:: Poreba

Model:: TPL90

Year:: 1988

Ref #:: 169273

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

POREBA 12-1/2" HOLLOW SPINDLE ENGINE LATHE
MODEL: TPL90 3M,  S/N: 1181-1197-044,  MFG: 1988

SPECIFICATIONS:
SWING OVER BED ....................... 36-1/2"
SWING IN REMOVABLE GAP ............... 45-2/7
SWING OVER CROSS SLIDE ............... 24-3/4"
SPINDLE NOSE CAMLOCK ................. A1-20
HOLE THROUGH SPINDLE ................. 12.5"
DISTANCE BETWEEN CENTERS ............. 120"
SPINDLE SPEED RANGE .................. 5 TO 250 RPM
LONGITUDINAL FEED RANGE (70) ......... .0043 - .249 IPR
CROSS FEED RANGE (70) ................ .0021 - .250 IPR
TOP SLIDE RANGE FEED (70) ............ .001 - .125 IPR
INCH THREADING RANGE (56) ............ .5 - 30 TPI
METRIC THREADING RANGE (62) .......... 1 - 60 MM
WIDTH OF BED ......................... 23"
TAILSTOCK SPINDLE DIAMETER ........... 5-1/8"
TAILSTOCK SPINDLE TAPER .............. #6MT
TAILSTOCK SPINDLE TRAVEL ............. 11-3/4"
APPROXIMATE FLOOR SPACE............... 74" X 230"
APPROXIMATE WEIGHT ................... 20,500 LBS.

EQUIPPED WITH:
- INCH & METRIC THREADING CAPABILITY
- TAPER TURNING ATTACHMENT
- POWER FEED TO THE TOP SLIDE
- (2) 4-JAW CHUCKS IN FRONT & REAR OF SPINDLE
- ALORIS QUICK CHANGE TOOLPOST
- LIVE CENTER
- THREAD DIAL INDICATOR
- COOLANT SYSTEM
- 6-WAY POWER & RAPID TRAVERSE
- TWO SPEED TAILSTOCK
- INDUCTION HARDENED & GROUND BEDWAYS
- 35 HORSE POWER MOTOR

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
