Sharp OD618A PLAIN CYLINDRICAL GRINDERS

Price on Request

Make:: Sharp

Model:: OD618A

Year:: 1999

Ref #:: 155913

Or call us for a quote at (973) 497-7500 or send us an email at grinders@machineryvalues.com

   6" X 18" SHARP/MADE BY SUPERTECH UNIVERSAL CYLINDRICAL GRINDER

MODEL: OD618A/G-10P450C     S/N: 29755        NEW: 2000

SWING ...................................... 6"
DISTANCE BETWEEN CENTERS ................... 18"

POWER TABLE TRAVERSE, THREE SPEEDS ......... 67", 108"& 211" IPM
SWIVEL TABLE GRADUATED ..................... +/- 8 DEGREES

WHEELHEAD:
WHEEL SPEEDS (2) ........................... 1620& 1960 RPM
WHEEL SIZE (DIA. X WIDTH X BORE) ........... 12" X 1" TO 2" X 5"
WHEELHEAD MOTOR ............................ 2 HP
AUTOMATIC WHEELHEAD INFEED ................. 0.0001" TO .004"

WORKHEAD:
WORKHEAD SWIVELS (LEFT& RIGHT) ....... ..... 45 DEGREES
WORKHEAD SPINDLE SPEEDS (4) ................ 150, 264, 356& 480 RPM
WORKHEAD CENTER TAPER . .................... #3 MT
WORKHEAD MOTOR ............................. 1/4 HP

TAILSTOCK:
QUILL TRAVEL ............................... 1"
SPINDLE TAPER .............................. #2 MT

APPROXIMATE WEIGHT ......................... 2,420 LBS
APPROXIMATE DIMENSIONS ..................... 60"L X 42"W X 52"H

EQUIPPED WITH:
POWER TABLE TRAVERSE
PROGRAMMABLE PLC AUTO INFEED CONTROL W/DIGITAL DISPLAY:
-PROGRAMMABLE AUTO INFEED @ TABLE REVERSALS
-PROGRAMMABLE AUTO PLUNGE FEED (COARSE& FINE FEED SELECTION)
-WHEELHEAD RETRACTS TO ORIGINAL POSITION AUTOMATICALLY
  AFTER CYCLE COMPLETION OF GRIND CYCLE
-SPARKOUT TIMER
QUICK ACTING LEVER-TYPE DRAWBAR (5C COLLETS)
COOLANT SYSTEM
CARRIAGE AND WHEELHEAD WAYS ARE AUTO LUBRICATED
MACHINE MOTORS ARE WIRED FOR 3/60/230-460 VOLT OPERATION


* * EXCELLENT CONDITION & APPEARANCE * *
** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
