Knuth Basic Plus Mechanics Lathe NEW LATHES

$9,100

Make:
Knuth
Model:
Basic Plus Mechanics Lathe
Year:
Ref #:
157491

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com



 BASIC PLUS MECHANICS LATHE

 *** 5 Year Warranty ***


Cast-iron bed, heavily ribbed
Hardened and ground headstocks gears
Induction-hardened and precision-ground box ways
Gap bridge
Headstock with Camlock D1-4" mount, bore diam. 1.5",
run in 2 adjustable tapered  roller bearings
Adjustable headstock bearing
Tailstock can be moved ± 0.4" mm for taper turning
Guides are adjustable via tapered gibs
Reversing gear reversing gearbox for changing the feed direction


3-axis position indicator
More accuracy
Lower error rate
Increased productivity
Resulting in valuable time savings
For increased productivity
Easy to read display
Operator-specific features
Convenient keyboard layout
Resolution: 0.0004 / 0.0002"
Default coordinates
Axis position is maintained when display is turned off
Hole circle pattern calculation
Calculator function
Storage for 10 tools
Radius / diameter toggle
Mm/inch conversion
Easy expansion and maintenance-free operation
Display for top (Z0) and box way slide (Z1) both separate
and in differential/cumulative mode for lathes


WORKING ARE:
Center width: 31.89 in
Turning diameter over bed: 12 in
Turning diameter over support: 7 in
Turning diameter over gap bridge: 17 in
Travel Z1-axis: 4 in
Bed width: 7 in
Swing range of top slide: ± 60°

TRAVELS:
Travel X-axis: 7 in

HEADSTOCK:
Sspindle Speed       (9) 60 - 1550rpm
Spindle bore         1 in
Spindle mount:       Camlock D1-4
Spimdle taper:       MK 5

FEED:
Feed X-axis:         0 - 0.01 in/R
Feed Z-axis:         0 - 0.05 in/R

TAPPING:
Tapping, metric:     (26) 0.02-0.3 in
Tapping, whithworth: (34) 4-56 TPI

TAILSTOCK:
Tailstock quill diameter: 1 in
Tailstock taper:          MK 3
Tailstock quill stroke:   4 in
Tailstock traverse adjustment: ± 0.5 in

DRIVE CAPACITY:
Motor rating main drive:  1.5 Hp


MEASURES AND WEIGHTS:
Overall dimensions: (Length x Width x Height): 62.99x29.53x50 in
Weight:  1,144 lbs

STANDARD EQUIPMENT:
3-axis position indicator
3-jaw chuck Ø 6"
4-jaw face platechuck Ø 8" (not for Basic 180V)
face plate Ø 10"
quick change tool holder WAD 1675
quick change tool holder head WA
steady and follow rest
chip tray
includes fixed splash guard (wall)
chuck guard
base
change gears
reducing sleeves
dead center
thread gauge
operating tools
operator manual
