Acer 1760G Dynamic Series NEW LATHES

Price on Request

Make:: Acer

Model:: 1760G Dynamic Series

Year:: NEW

Ref #:: 137478

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

"NEW" ACER High Speed Precision Engine Lathe
  MODEL: Dynamic Series - E-Lathe 1760G

SPECIFICATIONS:
Center Height: 8-3/4"
Swing Over Bed: 17"
Swing Over Gap (gap type only): 26"
Swing Over Cross Slide: 9-5/8"
Distance Between Centers: 60"
Spindle Nose: D1-6 or A1-6
Spindle Bore Diameter: 2-1/4"
Type of Spindle Nose: MT#6
Taper of Center: MT#4
Spindle Speeds: 50-1800 RPM (12 steps)
Cross Slide Travel: 9-4/5"
Compound Rest Travel: 7"
Max Size Cutting Tool: 1" x 1"
Spindle Diameter: 2-1/4"
Spindle Travel: 6"
Taper of Center: MT#4
Bed Length: 96.1"
Bed Width: 11-7/8"
Width of Gap: 8-3/4"
System: Inch/Metric
Pitch of Leadscrew: 35 Diameter, 4 TPI
Metric Pitch Threads: 0.5 - 7mm/pitch (22 kinds)
Inch Pitch Threads: 4-56 TPI (36 kinds)
Module Pitch Threads (optional): 0.5-3.5 MP (12 kinds)
Diametral Pitch Threads (optional): 8-56 DP (21 kinds)
Range of Longitudinal Feeds: 0.002" - 0.028"/rev.  0.05 -0.70mm/rev.
Range of Cross Feeds: 0.001"-0.014"/rev.  0.025 - 0.35mm/rev.
Main Drive Motor: 7-1/2 hp
Coolant Pump Motor: 1/8 hp
Floor Dimensions: 105" x 40"
Net Weight: 3950 lbs.
Gross Weight: 4250 lbs.
Packing Dimensions: 107" x 41" x 67"

Features:
2-1/4" Spindle Bore & D1-6 Camlock Spindle Nose
7.5 HP Spindle Motor
12 Spindle Speed: 50 ~ 1,800 RPM
Auto. Feed & theading are interlocked to prevent simultaneous functions
Hardened and Ground Meehanite Casting Bedway
Hardened and Ground Gears and Shafts
Thread Chasing Dial & Automatic Longitudinal Multiple Feed Stop

Standard Accessories:
10" D1-6 3-jaw chuck
4-Way Tool Post
Steady Rest 0.6" ~ 7" Capacity
14" Face Plate
Chuck Guard w/ Safety Switch
Built-In Coolant Systerm
Full Length Splash Guard
Work Light
Owner's Manual
Toolbox with Tools


Optional Accessories (call for pricing):
8” 3-Jaw Chuck (D1-6)
10” 4-Jaw Independent Chuck (D1-6)
12” 4-Jaw Independent Chuck (D1-6)
Follow Rest (Bronze Tip): 0.78” ~ 4.3” Range
12” Drive Plate
“ALORIS” Tool Post & 4-Holder Set (#3-BS)
“ALORIS” Tool Post & 6-Holder Set (#3 Set)
“DORIAN” Tool Post & 4-Holder Set (SD35CXA-TS)
Micrometer Stop
Four Position Carriage Stop
5C Collet Closer (Lever-Type)
Installation Fee on 5C Collet Closer
5C Collet Set (1/16” to 1-1/16” x 16ths; 17pcs/set)
Taper Turning Attachment
Installation Fee on Taper Turning Attachment
“NEWALL” NMS 800 2-Axis D.R.O. (10” x 40”/60”/80”)
“MAGNASCALE” 2-Axis D.R.O. (10” x 40”/60”/80”)
