GMC GML-2080 NEW LATHES

Price on Request

Make:: GMC

Model:: GML-2080

Year:

Ref #:: 162129

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

NEW GMC HEAVY DUTY PRECISION GAP BED LATHES
MOCEL GML-2080
WITH FREE TAPER ATTACHMENT AND FREE SINO DRO INSTALLED


 Machine Standard Features and Equipment:
• ISO 9001 certified
• Large spindle bore 3-1/8”
• Heavy Duty spindle D1-8
• Heavy Duty guideway width 12”
• Heavy Duty main motor 10HP
• 16 spindle speeds from 25-1,800 rpm, 12 speeds
 4-way rapid traverse on the carriage longitudinal and cross
• 60 kinds of inch threads, and 41 kinds of metric threads
• Threading and feeding rate change without changing gears
• Spindle is balanced, hardened and precision ground
• Spindle is supported at 3-point by high precision bearings
• All gears and shafts are hardened and precision ground
• Guideways induction hardened and precision ground
• Automatic lubrication system in headstock and feed box
• One year industrial warranty for parts

Heavy Duty Gap Bed Lathes Specifications
Max. swing over bed:  20”
Max. length of workpiece:  80”
Max. swing over cross slide:  12-1/2”
Max. Swing in gap:  29-1/8”
Width of Bed:  12”
Effective length in gap to spindle:  6”
Effective length in gap to chuck jaws:  3-1/2”
Spindle bore:  3-1/8” , D1-8
Taper of spindle center:  M.T.# 7
Spindle speeds:  25-1,800 rpm / 12 steps
Longitudinal feeds:  0.0011-0.063 IPR, 42 kinds
Cross feeds:  0.0003-0.018 IPR, 42 kinds
Inch threads:  2-112 TPI, 60 kinds
Metric threads:  0.1-14 mm , 41 kinds
Module threads:  0.1-7mm, 34 kinds
Diametral pitch threads:  4-112DP , 50 kinds
Max. travel of top slide:  5”
Max. travel of cross slide:  11-1/4”
Spindle length w/o chuck:  17-1/2”
Leadscrew length X TPI:  1-1/4” x 4 TPI
Diameter of tailstock quill:  2-3/8”
Max. travel of tailstock quill:  5-1/8”
Taper of tailstock quill center:  M.T. #4
Main motor:  10HP, 220V or 440V, 3 phase
Coolant pump motor:  1/8 HP, 220V, or 440V, 3 phase
Net weight, approx. LBS  6,350 LBS
Overall dimensions, LxWxH  128” x 43” x 59”

Standard Equipment
• Free Taper turning attachment, , installed
• Free SINO DRO, installed
4-way rapid traverse on the carriage longitudinal and cross
• Automatic kick-out longitudinal carriage stop system
• 10” 3-jaw chuck with top reversible jaws, direct mount
• 12” 4-jaw chuck, direct mount
• 14” Face plate
• 1/2”-6” steady rest with roller jaws
• 7/8" - 4-3/8" follow rest
• Removeable gap
• 4-way tools post
• Foot brake
• Halogen Work light and coolant system
• Full length splash guard
• Dead centers
• Thread chasing dial
• Tool box and leveling pads

Optional Equipment for Heavy Duty Lathes
• 5-C Hand lever type collet closer
• 33 pc 5C collet set, from 1/16”-1-1/16” by 32nd
• China ALORIS type QC tool post set # 900-0051-300, 6 pcs
• Live Center # 900-0050-04
• ¾ to 10-1/2” large steady rest with roller jaws
