Romi C-420 CNC LATHES, FLAT BED (ENGINE LATHE STYLE)

$29,500

Make:
Romi
Model:
C-420
Year:
2010
Ref #:
169196

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com


17" X 40" ROMI CNC COMBINATION LATHE
MODEL: C420,  S/N: 016-012455-448,  NEW: 2010

SPECIFICATIONS:
DISTANCE BETWEEN CENTERS..................... 43.46"
SWING OVER BED............................... 16.92"
SWING OVER CROSS SLIDE....................... 7.87"
CROSS SLIDE (X) TRAVEL....................... 8.66"
BED WIDTH.................................... 12.00"
BED HEIGHT................................... 13.77"
SPINDLE NOSE................................. A2-5 ASA
HOLE THROUGH SPINDLE......................... 2.08"
RANGE OF SPINDLE SPEEDS (INF VARIABLE)....... 4 - 4000 RPM
RAPID TRAVERSE (Z)........................... 393.70 IPM
RAPID TRAVERSE (X)........................... 393.70 IPM
TAILSOCK QUILL TRAVEL........................ 4.72"
QUILL DIAMETER............................... 2.36"
QUILL TAPER HOLE............................. 4MT
MAIN MOTOR................................... 10 HP
APPROXIMATE FLOOR SPACE ..................... 122" x 50"
APPROXIMATE WEIGHT .......................... 5,500 LBS

EQUIPPED WITH:
  - SIEMENS 802D CONTROL w/MANUAL GUIDANCE SOFTWARE, TOOL
  PATH& 3D PART SHAPE GRAPHICS, TEACH MODE, CONVERSATIONAL
  PROGRAMMING, G CODE PROGRAMMING, BUILT-IN DRO
  - 10 HP VARIABLE SPEED SPINDLE DRIVE
  - TURN PARTS MANUALLY OR AUTOMATICALLY
  - DUAL ELECTRONIC HANDWHEEL CONTROLS
  - "TEACH" 1ST PART, RUN REMAINING PARTS AUTOMATICALLY
  - USB PORT<, FLASH MEMORY CARD SLOT & RS 232 PORT
  - 10.4" COLOR LCD DISPLAY
  - AIR ACTUATED 5C COLLET CLOSER
  - RIGID TAPPING
  - CONSTANT SURFACE SPEED
  - INCH/METRIC CONVERSION
  - MULTI-START THREADING, THREAD REPAIR
  - FOURWAY TURRET TOOLPOST
  - BORING BAR HOLDER
  - COOLANT SYSTEM
  - AUTOMATIC LUBRICATION SYSTEM

INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE




DISCLAIMER: The information presented in the write ups and the photographic representations of the equipment are believed to be accurate at the time the pages are created. The information presented on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Machinery Values claims no responsibility for inaccuracies of the information presented on the pages of this website. Please contact one of our sales representatives if you require more information or a current formal quotation.
