Victor 2460T w/Special Package NEW LATHES

Price on Request

Make:: Victor

Model:: 2460T w/Special Package

Year:: NEW

Ref #:: 147955

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

NEW VICTOR 24" x 60" PRECISION HIGH SPEED LATHE
MODEL: 2460T       *MADE IN TAIWAN*

FEATURES:


  High precision hardened and ground spindle
Hardened and precision ground induction bedways with high tension mechanize casting iron

Spindle is supported by 3 bearings (2 taper roller bearings and one ball bearing)

4-1/8" large spindle bore with D1-11 Camlock spindle nose

Magnetic multiple-disc clutches are used for efficient starting and reversing the spindle

Rapid and positive magnetic disc brake interconnected with main clutcher operated by emergency switch control or foot pedal

All running parts are lubricated by a pressure pump in gearbox

Sliding, surfacing, and screw-cutting motions are fully interlocked in apron

A cone-clutch device in the apron to prevent overload

Dual speed tailstock quill (ratio 1:1, 1:4) provides easy drilling operation

4-way power rapid traverse

Ampere meter for power consumption

Jog button for easy spindle speed changes
















MACHINE INCLUDES:

  20" 4-jaw chuck
Steady rest (14.5" capacity)
Follow rest
4-way tool post
Micro bed stop
Halogen work light
Chuck cover with limit switch



SPECIAL PACKAGE INCLUDES:

  20" 4-jaw chuck
Steady rest 15" (7" ~ 13")
Follow rest
4-way tool post
Face plate
Micro bed stop
Halogen work light
Chuck cover w/ limit switch


SPECIFICATIONS:


Swing over bed: 23-5/8"
Swing over cross slide: 15"
Swing over gap: 32-1/4"
Bed width: 16-1/2"
Distance between centers: 53"
Spindle bore diameter: 4-1/8"
Spindle bore taper: 108 x 1 : 20
Taper of center in sleeve: M.T. #5
Spindle nose: D1-11
Number of spindle speeds: 12 steps
Range of spindle speeds (rpm): 25 ~ 1,200 rpm
Speed selections: 25, 38, 53, 75, 108, 149, 214, 308, 424, 603,
860, 1200
Range of longitudinal feeds: 0.0012" ~ 0.0287" / rev
Range of cross feeds: 0.0004" ~ 0.0118" / rev
Inch threads: 2 ~ 56 TPI x 45 kinds
Cross slide travel: 13 "
Compound slide travel: 9"
Tailstock taper center: M.T. #5
Tailstock quill travel: 7"
Main motor: 20 HP  3 PH
Coolant pump: 1/8 HP
Shipping dimensions: 120" x 54" x 75"
Gross weight: 8,250 lbs.


OPTIONS (Call for pricing):


Steady rest with rollers support
Follow rest
3-jaw scroll chuck
4-jaw independent chuck
Face plate
Drive plate
Digital readout
Micro carriage stop
Extension quills for 15" steady rest
Live center M.T. #5
Halogen work light
Full length splash guard
Taper turning attachment
Quick change tool post
Steady rest 19" with rollers support
