Victor S2240S w/Special Package NEW LATHES

Price on Request

Make:: Victor

Model:: S2240S w/Special Package

Year:: NEW

Ref #:: 147950

Or call us for a quote at (973) 497-7500 or send us an email at toolroom@machineryvalues.com

NEW VICTOR 22" x 40" PRECISION HIGH SPEED LATHE
MODEL: S2240S       *MADE IN TAIWAN*

FEATURES:


  Hardened and precision ground chromium molybdenum steel gears in headstock
Hardened and ground bed ways

Meehanite casting bed

Large 4-1/8" spindle bore with D1-11 spindle nose

Spindle speed range 15 ~ 1,200 rpm

Carriage with mechanical overload device

Turcite B coated slideways between saddle and bed

Cross slide is induction hardened to HRC 52º and precision ground

2-speed tailstock quill speed

Universal inch/metric gearbox

Dual speed tailstock quill (ratio 1:1, 1:5) provides easy drilling operation

2-way longitudinal (z-axis) power rapid traverse on S22100S and S22120S















MACHINE INCLUDES:

Center sleeve M.T. #5 / #7
Tool box with kits
D.P. & M.P. Change gear
Rapid feed motor for S22100S (S26100), S22120S ( S26120S), & S22160S (S26160S) only
Leveling screw
Thread dial indicator
Dead center M.T. # 5
Operation manual & parts list
Coolant system


SPECIAL PACKAGE INCLUDES:

Steady rest
4-way tool post
Halogen work light
Chuck cover w/ Limit switch
Full length splash guard for S22040S, S22060S, and S22080S only
On-carriage splash guard for S22100S and S22120S only


SPECIFICATIONS:


Swing over bed: 22"
Swing over cross slide: 14-1/8"
Swing in gap diameter: 29-3/8"
Length of gap infront of face plate: 6-1/2"
Between centers: 40"
Width of bed: 15-3/4"
Spindle motor: 15 HP 3 PH
Spindle bore: 4-1/8
Spindle nose: D1-11 Camlock
Spindle taper in nose/sleeve: M.T. #8
Speed number: 12 steps
Speed ranges: 15 ~ 1,200 RPM
Cross slide travel: 12-1/2"
Compound rest travel: 10"
Leadscrew diameter & thread: 1-1/2"
Imperial threads: 2 ~ 112 TPI x 60 kinds
Diametral pitch threads: 4 ~ 112 D.P. x 50 kinds
Module pitch threads: 0.2 ~ 7 M.P. x 50 kinds
Longitudinal feeds: 0.0014" ~ 0.0387" / rev x 50 kinds
Cross feeds: 0.0007" ~ 0.01935" / rev x 50 kinds
Quill diameter/travel: 2-15/16" / 6-5/16"
Quill taper: M.T. No. 5
Length of machine: 100"
Width of machine: 50-3/8"
Machine height: 51-3/8"
Packing dimensions: 101 x 45 x 67
Net weight: 5,082 lbs


OPTIONS (Call for pricing):


Four-way tool post
Quick change tool post
American tool post
Digital readout
3-jaw scroll chuck
4-jaw independent chuck
Chuck cover
Steady rest with roller support
Live center M.T. No. 5
Follow rest
Face plate
Full length splash guard
Micro carriage stop
Taper turning attachment
Lever type 5C collet closer
5C collet set
Halogen work light
